GPSLOGGER SOFTWARE
Use SkyRC application software “GPS Logger” to transfer the logged data to PC and easily export the logged data to “Google Earth”.
GpsLogger Software Application
- Transfer the logged data to PC and show the track data on Google Earth
- Save the logged data to PC
- Select the language between English and Chinese
- Change Metric and Imperial system of measurement
- GPS update rate selection
- Firmware upgrade
Features:
- Compact and easy to carry
- Speed meter with top speed memory
- Peak altitude memory
- GPS Coordinator
- Built-in 4M flash (recording time: 6 hours)
- UTC timestamp logged for each track point
- Built-in rechargeable, LiPo battery 200mAh
- (Operating time: 150 minutes)
- Support both Metric and Imperial system of measurements
- PC link for data logging & google map
- Firmware upgrade-able
Specifications:
Receiver: L1, 1575.42 MHZ
Frequency: 1.023 MHZ
Update frequency: 1 Hz.
Antenna type: Built-in
Satellite signal reception sensitivity: -159dBm
Dimensions: 65.7x39.6x20.8mm
Weight: 41g
Operating temperature: 0° to +50°
Storage temperature: -10° to +60°
Operating humidity: 5% to 90%
