| Application |
1/10, 1/8 & 1/7 Surface |
| Operating Voltage |
4.8-8.4V |
| Operating Temperature |
14° to 140° F (-10 to +60° C) |
| Operating Speed @ 6.0V |
0.14/60° sec |
| Operating Speed @ 7.4V |
0.12/60° sec |
| Operating Speed @ 8.4V |
0.10/60° sec |
| Dynamic Torque @ 6.0V |
574oz-in (41.3 kg-cm) |
| Dynamic Torque @ 7.4V |
681oz-in (49 kg-cm) |
| Dynamic Torque @ 8.4V |
758oz-in (54.5 kg-cm) |
| Motor Type |
Brushless Digital |
| Output Shaft |
25T |
| Gears |
Metal w/Lifetime Gear Warranty
|
| Pulse/Frequency |
1520s / 333hz |
| Dimensions |
1.56x0.79x1.55in (39.5x20x39.25mm) |
| Weight |
2.7oz (76.6g) |
